C series 4:3 P2.0 to P3.076
Tell us about your space and we reply with pricing and lead times.
C series 4:3 (1) has seamless, perfect display characteristics, long lifetime, fast frame changing speed, high refresh, good uniformity, wide viewing angle, high grayscale, natural color reproduction, etc. It is widely used in command and dispatch center, security monitoring, video conference, exhibition, large stage, convention and exhibition center, indoor stadium, various indoor conference room display area.
Specifications
| Model | C2.0 | C2.5 | C3.0 |
|---|---|---|---|
| LED encapsulation | SMD1515 black light | SMD2121 black light | SMD2121 black light |
| Pixel pitch | 2.0mm | 2.5mm | 3.076mm |
| Resolution | 250000 pixels/m² | 160000 pixels/m² | 105625 pixels/m² |
| Module resolution | 160*80 | 128*64 | 104*52 |
| Module size (mm) | 320*160 | 320*160 | 320*160 |
| Cabinet resolution | 320*240 | 256*192 | 208*156 |
| Cabinet size (mm) | 640*480*31.5 | 640*480*31.5 | 640*480*31.5 |
| Best viewing distance | ≥6m | ≥7.5m | ≥9.0m |
| Viewing angle (H/V) | ≥175° | ≥175° | ≥175° |
| Refresh rate | ≥4200Hz | ≥4200Hz | ≥4200Hz |
| Frame rate | ≥60Hz | ≥60Hz | ≥60Hz |
| Scanning method | 40S | 32S | 26S |
| Brightness | 200-600CD/m² | 200-600CD/m² | 200-600CD/m² |
| Contrast | ≥10000:1 | ≥10000:1 | ≥10000:1 |
| Lifespan | ≥100000H | ≥100000H | ≥100000H |
